Product testing



  Composite busbars are, according to their definition, high-efficiency solutions for connecting components or submodules of converters or drives. It distributes power from one component to another component or from the input side to the output side of the high-power module. The company provides reliable solutions for the connection between busbars and busbars, and between busbars and components.

    The company can also provide assistance to the engineers of the client company in choosing the correct connection technology, taking into account different parameters, such as current volume, flexibility, etc. By making full use of the company's actual knowledge and production capabilities, you can ensure that you get a reliable, long-lived, and optimal electrical matching solution.

The main main advantages of the various connection technologies provided according to customer requirements:

1. Large current

2. Reduce leakage inductance

3. Minimum contact resistance

4. Minimal power loss

5. Easy to install and replace

6. Long life

7. Corrosion resistance

8. Space saving

material	Continuous use temperature	Compressive strength	Dielectric constant	Flammability rating	Thermal conductivity	Basic performance	价格
Epoxy resin	155	15.7KV/mm	3.5-4.0	94 V-0	0.18	Stable chemical properties, low hygroscopicity, flame retardant	低
PI (Polyimide)	260	13.8KVAC(3mil)	3.70	94-0	0.094	Excellent heat resistance, good electrical properties, flame retardant	cutting bending machine.0000pt solid #000000;background:#66FFFF;"> 高
PET	150	10.0KVAC(3mil)	3.30	94 V-0	0.128	Good electrical properties and chemical resistance;	低
NOMEX	220	1.6KVAC(3mil)	1.60	94 V-0	0.143	Excellent fire resistance, heat resistance, good chemical resistance, flame retardant	高
Polyvinyl fluoride (PVF)	260	4.2KVAC(2mil)	11.0	94 V-0	0.12	Excellent mechanical properties Stable chemical properties, not easy to melt	高
NMN	155	14KV/mm	2.4	94V-1	0.136	Good electrical properties, good mechanical properties, good resistance to breakdown and overload, flame retardant	中
DMD	155	11 KV/mm	4.3	94V-1	0.129	High heat resistance, excellent electrical properties,机械性能好	低
NHN	155	8 KV/mm	4.8	94V-0	0.141	Excellent electrical properties, good resistance to breakdown and overload, flame retardant	高
